SICK KHK53-AXB00548 Sensor
SICK KHK53-AXB00548 magnetic linear encoder, part 1035449. Contactless position feedback for linear motors and machine tool axes.
Overview
The SICK KHK53-AXB00548 (part number 1035449) is a magnetic linear encoder. It records position along a magnetic scale without contact and delivers high-resolution position feedback for linear motors, machine tools and precision axes where optical scales would be at risk from contamination.
How It Works
A magnetic scale carries finely graduated pole pairs. The reading head senses the magnetic pattern as it travels along the scale and converts it into incremental position signals. Because the sensing is magnetic, dust, oil and typical workshop contamination do not affect the measurement.
Key Features
- Contactless magnetic linear position measurement
- Part number 1035449
- Insensitive to dust, oil and shop-floor contamination
- High-resolution position feedback for motion control
- Suitable for direct drives and precision axes
- Compact reading head for tight installation spaces
Typical Applications
- Position feedback for linear motors
- Closed-loop control on machine tool axes
- Position measurement on precision assembly equipment
- Feedback on semiconductor and electronics machinery
- Metrology-style feedback on precision stages
Specifications
Attribute | Value |
|---|---|
Model | SICK KHK53-AXB00548 |
Part number | 1035449 |
Encoder type | Magnetic linear encoder |
Detection principle | Contactless magnetic scale scanning |
Installation and Setup Notes
Mount the scale along the axis of travel with uniform spacing to the reading head as specified by the family, and align the head to minimize signal variation. Verify signal quality across the full travel after installation. Keep the scale free of swarf that could mechanically bridge the gap.
Frequently Asked Questions
Why magnetic instead of optical?
Magnetic scales tolerate dust, oil and swarf that quickly blind optical scales, ideal for machine-tool environments.
What measuring lengths are possible?
The scale is supplied per the order code length; family variants cover a wide range of axis lengths.
Which interface does it use?
The order code defines the signal interface; match it to the drive or controller input.
